Robot collaborativi
Costruiti per il futuro dell'automazione
Questa nuova linea di robot collaborativi è più sicura, più semplice da programmare e da integrare con altre apparecchiature, e rappresenta un grande passo avanti verso la creazione di un ambiente di produzione intelligente in cui esseri umani e macchine lavorano in armonia.
- Meno programmazione e cambi di produzione più rapidi contribuiscono alla realizzazione di prodotti diversificati a volumi ridotti da parte delle aziende.
- La sicurezza come priorità. Requisiti di sicurezza conformi alla norma tecnica ISO 10218 e alla specifica tecnica ISO/TS 15066.
- La programmazione semplificata di questi robot non richiede alcuna codifica e alcuna pulsantiera, garantendo all'utente tempi di avvio più veloci.
- Massima versatilità e adattabilità a svariate applicazioni, in particolare all'asservimento macchine, caricamento e scaricamento, assemblaggio, incollaggio, testing e saldatura.
- Integrazione perfetta garantita con i nostri robot collaborativi (ad es. robot mobili LD) e l'hardware del controller.
- Sistema di visione intelligente integrato per il riconoscimento degli schemi, il posizionamento degli oggetti e l'identificazione con codice a barre.
Ordering information
Robots
TM5
| Type | Max. Payload |
Reach | Overview | Bundled accessories | Power supply | SEMI C2 Certified |
Cable length | Product name | Order code |
|---|---|---|---|---|---|---|---|---|---|
| TM5-700 | 6 kg | 700 mm | Robot and control box with built-in vision system. |
|
100–240 VAC, 50–60 Hz |
– | 3 m | TM5-700 | RT6-0007001 |
| 12 m | TM5-700, 12 m cable |
RT6-0007002 | |||||||
| 22–60 VDC | 1.5 m | TM5M-700 | RT6-0107001 | ||||||
| Yes | TM5M-700 SEMI | RT6-0107011 | |||||||
| Robot and control box without vision system. |
100-240 VAC, 50-60 Hz |
– | 3 m | TM5X-700 | RT6-0017001 | ||||
| 12 m | TM5X-700, 12 m cable |
RT6-0017002 | |||||||
| 22-60 VDC | 1.5 m | TM5MX-700 | RT6-0117001 | ||||||
| TM5-900 | 4 kg | 900 mm | Robot and control box with built-in vision system. |
100–240 VAC, 50–60 Hz |
– | 3 m | TM5-900 | RT6-0009001 | |
| 12 m | TM5-900, 12 m cable |
RT6-0009002 | |||||||
| 22–60 VDC | 1.5 m | TM5M-900 | RT6-0109001 | ||||||
| Yes | TM5M-900 SEMI | RT6-0109011 | |||||||
| Robot and control box without vision system. |
100-240 VAC, 50-60 Hz |
– | 3 m | TM5X-900 | RT6-0019001 | ||||
| 12 m | TM5X-900, 12 m cable |
RT6-0019002 | |||||||
| 22-60 VDC | 1.5 m | TM5MX-900 | RT6-0119001 |
TM12/14
| Type | Max. Payload |
Reach | Overview | Bundled accessories | Power supply | SEMI C2 Certified |
Cable length | Product name | Order code |
|---|---|---|---|---|---|---|---|---|---|
| TM12 | 12 kg | 1,300 mm | Robot and control box with built-in vision system. |
|
100–240 VAC, 50–60 Hz |
– | 3 m | TM12 | RT6-1001301 |
| 12 m | TM12, 12m cable | RT6-1001302 | |||||||
| 22–60 VDC | 1.5 m | TM12M | RT6-1101301 | ||||||
| Yes | TM12M SEMI | RT6-1101311 | |||||||
| Robot and control box without vision system. |
100-240 VAC, 50-60 Hz |
– | 3 m | TM12X | RT6-1011301 | ||||
| 12 m | TM12X, 12m cable | RT6-1011302 | |||||||
| 22-60 VDC | 1.5 m | TM12MX | RT6-1111301 | ||||||
| TM14 | 14 kg | 1,100 mm | Robot and control box with built-in vision system. |
100–240 VAC, 50–60 Hz |
– | 3 m | TM14 | RT6-2001101 | |
| 12 m | TM14, 12m cable | RT6-2001102 | |||||||
| 22–60 VDC | 1.5 m | TM14M | RT6-2101101 | ||||||
| Yes | TM14M SEMI | RT6-2101111 | |||||||
| Robot and control box without vision system. |
100-240 VAC, 50-60 Hz |
– | 3 m | TM14X | RT6-2011101 | ||||
| 12 m | TM14X, 12m cable | RT6-2011102 | |||||||
| 22-60 VDC | 1.5 m | TM14MX | RT6-2111101 |
Accessories & Software
Accessories
| Appearance | Product Name | Description | Order code |
|---|---|---|---|
 |
Landmark | Robot positioning tool as a reference to the environment (2 units included with the robot). | RT6-A000008 |
 |
Mobile Workstation (MWS) | MWS is a convenient tool for users to mount the robot arm on work surface, and store the control box safely within. Users can move the MWS with the robot to different work cells easily. (Compatible with OMRON TM5 only). |
RT6-A000010 |
 |
Robot stand | The robot stand can be moved with the robot to different work stations easily. Height adjustable. (Compatible with OMRON TM5 only). |
RT6-A000009 |
 |
SSD with cable | 128 GB solid state hard drive. SATA cable included. Recommended for external cameras image logging. |
RT6-A000012 |
 |
Kit, calibration set with additional pin | Toolkit for teaching a precise tool center point (TCP) that can be used for manual workspace calibration within TMvision. Required for TCP and manual vision calibration. |
RT6-A000002 |
 |
Robot stick stand | Mounting fixture for the robot stick. Can be used on desktops, walls, and MWS. |
RT6-A000000 |
 |
Pneumatic control box | Controls the inputs and outputs and monitors air pressure for Kilews screw driving applications. Compatible with Kilews screw driving solution kit only. Recommended to attach to the robot stand. |
RT6-A000015 |
Software
| Product Name | Add-On Product Name | Remarks | Order code |
|---|---|---|---|
| USB Dongle | – | Required for all extra software licenses. | RT6-A000004 |
| TMflow | – | Software required to control the cobot. | N/A, Free Download |
| TM Identify & Measure | License, add-on to TMflow. Includes: identification of pose variation, specific color area size, subtract reference image, line/circle burr, counting and gauge. |
RT6-S100000 | |
| TM External Vision | License, add-on to TMflow. Required when using eye-to-hand cameras. |
RT6-S100002 | |
| TM OCR | License, add-on to TMflow. Includes: Text OCR and Number OCR. |
RT6-S100003 | |
| TMflow Editor | – | License, provides a convenient way to open and edit project offline. |
RT6-S200001 |
| TMflow Editor - Offline AOI | License, add-on to TMflow Editor. Enables TMflow Editor to offline edit a TMflow project that includes AOI vision. |
RT6-S100005 |
Omron Plug & Play Hardware
| Appearance | Category | Product Name | Omron Part Number | |
|---|---|---|---|---|
 |
Grippers | Adaptive gripper 2-Finger 85/140 for OMRON TM robot A 2-finger adaptive gripper that can adapt to parts of various shapes and sizes. Comes in two stroke options – 85 mm and 140 mm. Each kit includes: - End effector coupling kit - 10-meter communication cable - RS485 to RS232 converter - RS485 to USB converter - Screw kit - Quick start guide |
85 kit: AGC-OMRON-KIT-85 140 kit: AGC-OMRON-KIT-140 |
|
 |
Hand-E gripper for OMRON TM robot A 2-finger parallel gripper with an IP67 rating. 50 mm stroke. Each kit includes: - Fingertip starting kit - End effector coupling kit - 10-meter communication cable - RS485 to RS232 converter - RS485 to USB converter - Screw kit - Quick start guide |
HND-OMRON-KIT | ||
 |
EPick gripper for Omron TM robot A vacuum gripper that uses an integrated vacuum generator. Each kit includes: -Basic gripper unit -End effector coupling kit -10-meter communicable cable -RS485 to RS232 converter -RS485 to USB converter -Quick start guide -Vacuum cup(s): 1.5 bellows, 55 mm diameter KIT1 includes 1 vacuum cup KIT2 has a suction system for 2 cups KIT4 has a suction system for 4 cups |
VAC-OMRON-EPICK-KIT1 | ||
 |
VAC-OMRON-EPICK-KIT2 | |||
 |
VAC-OMRON-EPICK-KIT4 | |||
 |
AirPick gripper for Omron TM robot A vacuum gripper that uses an external pneumatic supply. Each kit includes: -Basic gripper unit -Tubing 8 mm-8 m -End effector coupling kit -RS485 to RS232 converter -RS485 to USB converter -Quick start guide -Vacuum cup(s): 1.5 bellows, 55 mm diameter KIT1 includes 1 vacuum cup KIT2 has a suction system for 2 cups KIT4 has a suction system for 4 cups |
VAC-OMRON-AIRPICK-KIT1 | ||
 |
VAC-OMRON-AIRPICK-KIT2 | |||
 |
VAC-OMRON-AIRPICK-KIT4 | |||
 |
Kit 4 suction cups | VAC-SCS-TM4 | ||
| I/O Coupling Component that connects the Robotiq adaptive/vacuum gripper to the wrist of the OMRON TM robot to eliminate the need for an external serial communication cable. Each kit includes: - I/O Coupling - Screw kit - Micro-USB to USB cable - 16G USB Stick |
IO-CPL-OMRON-KIT | |||
| Dual-Grip Adapter Plate Adapter plate and mounting screws to mount two grippers onto the OMRON TM robot. |
AGC-APL-159-002 | |||
| 2F-85 Dual kit for OMRON Robots 2F-140 Dual kit for OMRON Robots HAND-E Dual kit for OMRON Robots Kit that enables dual gripper setting. Each kit includes: - Chosen gripper x 2 - Mechanical coupling x 2 - USB to RS485 Adapter - Communication Cable - M12 5 Pins Splitter - Dual-Grip Adapter Plate - Screw kit x 2 |
OMRON-DUAL-AGC-85 OMRON-DUAL-AGC-140 OMRON-DUAL-HND |
|||
 |
Force Sensor | FT-300 Six-axis force/torque sensor with RS485 Serial Communication. Each kit includes: - Coupling - RS485 to RS232 converter - Power and communication cable with USB adapter - Screw kit |
FTS-300-OMRON-KIT | |
3rd party Plug & Play Hardware
| Appearance | Category | Product Name | Manufacturer SKU Number
2
Manufacturer SKU
numbers are 3rd party part numbers, not OMRON part numbers. |
|
|---|---|---|---|---|
| Grippers | OnRobot RG2 Gripper Electric 2-finger gripper. Each kit includes: - RG2 Gripper - Fingertip adapters (pre-mounted) - Integrated Quick Changer (tool side) - Torx key |
102012 | ||
| OnRobot RG6 Gripper Electric 2-finger gripper with larger stroke. Each kit includes: - RG2 Gripper - Fingertip adapters (pre-mounted) - Integrated Quick Changer (tool side) - Torx key |
102021 | |||
 |
OnRobot VG10 Electric Vacuum Gripper Flexible and adjustable electrical vacuum gripper. Each kit includes: - VG10 Gripper - d 30 mm suction cups x 16 (pre-mounted) - Integrated Quick Changer (tool side) - d 40 mm suction cups x 4 - d 15 mm suction cups x 4 - Blind screws x 16 - Positioning arrows - Torx key |
101661 | ||
| OnRobot Gecko Gripper Gripper that uses van der Waals force to pick up flat and porous objects without compressed air. Each kit includes: - Gecko Gripper - Gecko Pads x 4 (pre-mounted) - Integrated Quick Changer (tool side) - Spare Gecko Pads x 8 - Pad removal tools |
102215 | |||
| OnRobot Quick Changer-robot side Manual tool changer to attach on the robot’s end-of-arm. Either the Quick Changer (robot side) or the Dual Quick Changer must be purchased for use of all OnRobot grippers. Each kit includes: - Quick Changer robot side - Screws - Torx key |
102037 | |||
| OnRobot Quick Changer- tool side Manual tool changer to attach on the tool side. (All OnRobot grippers have this component integrated, so this is only necessary when user is developing own tool.) |
102014 | |||
| OnRobot Quick Changer Kit Each kit includes: - Quick Changer (robot side) x 1 - Quick Changer (tool side) x 2 - Torx key - Screws and pins |
102277 | |||
| OnRobot Dual Quick Changer Manual tool changer to attach on the robot’s end-of-arm for dual gripper configuration. Either the Quick Changer (robot side) or the Dual Quick Changer must be purchased for use of all OnRobot grippers. Each kit includes: - Dual Quick Changer - Screws - Torx key |
101788 | |||
| Grippers | OnRobot OMRON TM Robot Kit This kit must be purchased for the use of OnRobot grippers on OMRON TM collaborative robot. Each kit includes: - Compute Box - Power supply - Adapter plate (included in all kits but only necessary for VG10 and Gecko grippers) - USB stick with software components and User Manual - Device cable 5 m - UTP cable 0.5 m - I/O cable 0.3 m - Cable management hook/loop |
102359 | ||
| Schmalz ROB-SET ECBPi OMRON Complete vacuum gripper for collaborative robots. Each kit includes: - Vacuum generator (ECBPi) - End-effector coupling kit - Connection cable - Mounting flange - Flat suction cup - Bellows suction cup - Bolts and t-nuts - Operating instructions |
10.03.01.00544 | |||
| Schmalz ROB-SET FXCB OMRON Area gripper equipped with integrated pneumatic vacuum generation. (Needs external air supply.) Each kit includes: - Pneumatic area gripper (FXCB) - Connection cable - Mounting flange - Bolts and t-nuts - Operating instructions |
10.01.43.00120 | |||
| Schunk Co-act EGP-C 40 N-N-TMID Electric 2-finger parallel gripper certified for collaborative operation with actuation via 24 V and digital I/O. Each kit includes: - Co-act EGP-C gripper - Assembly and Operating Manual - Accessory pack |
1374363 | |||
| Schunk Co-act AUB EGP 40/12 Schunk Co-act AUB EGP 40/24 Schunk Co-act AUB-F EGP 40/xx Gripping fingers for Co-act EGP-C. |
1401285 1401286 1409839 | |||
| 3D Bin Picking | Pick-it M Plug & Play 3D camera and software for picking objects sized 50 x 50 x 10 mm or larger. Each kit includes: - Pre-calibrated 3D camera - Pick-it software - Industrial processor - 3G dongle to connect directly to Pick-it support - Calibration plate and ROi box teaching markers - All connection cables (plug & play) - Quick start guide |
PI-M-2.0 | ||
| Pick-it M-HD Plug & Play 3D camera and software for picking objects sized 10 x 10 x 5 mm or larger. Each kit includes: - Pre-calibrated 3D camera - Pick-it software - Industrial processor - 3G dongle to connect directly to Pick-it support - Calibration plate and ROi box teaching markers - All connection cables (plug & play) - Quick start guide |
PI-M-HD | |||
 |
Screw Driving | Kilews screw driving solution kit Screwdriver kit and pneumatic control box. Each kit includes: - Screwdriver SKD-BN512LM - Power Controller SKP-32BC-60W - Flange E31700-3 - Air Nozzle KS-TM-B500 - Signal box - Pneumatic control box - Installation guide |
– | |
 |
Vision | Basler GigE camera, 5 MP, CMOS 1/2.5'', 14fps | Color | acA2500-14gc, Rolling Shutter |
| Monochrome | acA2500-14gm, Rolling Shutter | |||
| Basler GigE camera, 5 MP, CMOS 1'', 21fps | Color | acA2500-20gc, Global Shutter | ||
| Monochrome | acA2500-20gm, Global Shutter | |||
| Basler GigE camera, 5 MP, CMOS 2/3'', 23fps | Color | acA2440-20gc, Global Shutter | ||
| Monochrome | acA2440-20gm, Global Shutter | |||
| Basler GigE camera, 10 MP, CMOS 1/2.3'', 10ps | Color | acA3800-10gc, Rolling Shutter | ||
| Monochrome | acA3800-10gm, Rolling Shutter | |||
| Basler GigE camera, 12.2 MP, CMOS 1/1.7'', 8fps | Color | acA4024-8gc, Rolling Shutter | ||
| Monochrome | acA4024-8gm, Rolling Shutter | |||
 |
Force Sensor | ATI Axia80 Six-axis force/torque sensor with EtherCAT communication. Each kit includes: - Interface plate - Power and Ethernet cable - Digital delivery of calibration documents and user manual |
9105-TM-Axia80 | |
 |
Connectivitiy | ADLINK EtherCAT I/O Expansion Modules | Kit A Kit that includes: chassis w/EtherCAT ports and voltage input, 32-channel digital output module, 32-channel digital input module. |
EPS - 9905+6000+2032+1132 |
| DO module 32-channel digital output module. |
EPS-2032 | |||
| DI module 32-channel digital input module. |
EPS-1132 | |||
 |
Advantech Serial Device Server EKI-1524-CE External device with serial ports that communicates with the robot via TCP/IP. |
EKI-1524-CE | ||
| Advantech Modbus to PROFINET Gateways A gateway to transform Omron TM cobot’s Modbus to PROFINET, whereby Omron TM cobot as slave could communicate with PROFINET master devices. |
EKI-1242IPNMS | |||
 |
Cable Management | Murrplastik FHS-C-SET Cable management dress pack. Each kit includes: - Conduit (Cable routing hose, Length: 2 m, Interior diameter: ~21 mm) - 4x Attachment straps - 2x End plugs - Cable insertion tool - Installation instructions |
For TM5 models | 83693500 |
| For TM12 and TM14 models | 83693501 | |||
 |
Murrplastik FHS-RS-SET Cable management dress pack. Each kit includes: - Conduit (Cable routing hose, Length: 2 m, Interior diameter: ~21mm) - 2 x Conduit clamps - Self-retracting hose guide (2 x Ball joint fixing, Ball joint strain relief, Feedback system, System holder) - Tool-end clamp - End sleeve - Cable puller - Installation instructions |
For TM5 models | 83693506 | |
| For TM12 and TM14 models | 83693507 | |||
Specifications
TM5
| Product name | TM5-700 | TM5M-700 | TM5M-700 SEMI | TM5-900 | TM5M-900 | TM5M-900 SEMI | |
|---|---|---|---|---|---|---|---|
| Model | RT6-000700 |
RT6-010700 |
RT6-010701 |
RT6-000900 |
RT6-010900 |
RT6-010901 |
|
| Weight (kg) | 22.1 | 22.6 | |||||
| Max Payload (kg) | 6 | 4 | |||||
| Reach (mm) | 700 | 900 | |||||
| Mounting | Wall, Table, Ceiling | ||||||
| Typical Speed (m/s) | 1.1 | 1.4 | |||||
| Joint Range | Joint 1 | ±270° | |||||
| Joint 2, 4, 5 | ±180° | ||||||
| Joint 3 | ±155° | ||||||
| Joint 6 | ±270° | ||||||
| Joint Speeds | Joint 1, 2, 3 | 180°/s | |||||
| Joint 4, 5, 6 | 225°/s | ||||||
| Repeatability (mm) | ±0.05 | ||||||
| IP | IP54 (robot arm), IP32 (control box), IP40 (robot stick) | ||||||
| Cleanroom Class | ISO Class 5 | ||||||
| Operating Temperature (°C) | 0 to 50 | ||||||
| Power Supply | 100-240 VAC, 50-60 Hz | 22-60 VDC | 100-240 VAC, 50-60 Hz | 22-60 VDC | |||
| Cable length | 3 m/12 m | 1.5 m | 3 m/12 m | 1.5 m | |||
| I/O Ports | Control Box | Digital In: 16 Digital Out: 16 Analog In: 2 Analog Out: 1 |
|||||
| Tool | Digital In: 4 Digital Out: 4 Analog In: 1 Analog Out: 0 |
||||||
| I/O Interface | 3 × COM, 1 × HDMI, 3 × LAN, 4 × USB2.0, 2 × USB3.0 | ||||||
| Communication | RS232, Ethernet (master), Modbus TCP/RTU (master & slave) | ||||||
| Integrated Camera | 5M pixels, color (AOI tasks: 5M/1.2M; others:1.2M) | ||||||
| I/O Power Supply | 24 V 1.5 A (control box and tool) | ||||||
| Programming Environment | TMflow, flowchart based | ||||||
| SEMI S2 Certified | No | Yes | No | Yes | |||
TM12/14
| Product name | TM12 | TM12M | TM12M SEMI | TM14 | TM14M | TM14M SEMI | |
|---|---|---|---|---|---|---|---|
| Model | RT6-100130 |
RT6-110130 |
RT6-110131 |
RT6-200110 |
RT6-210110 |
RT6-210111 |
|
| Weight (kg) | 33.3 | 32.6 | |||||
| Max Payload (kg) | 12 | 14 | |||||
| Reach (mm) | 1300 | 1100 | |||||
| Mounting | Wall, Table, Ceiling | ||||||
| Typical Speed (m/s) | 1.3 | 1.1 | |||||
| Joint Range | Joint 1 | ±270° | |||||
| Joint 2, 4, 5 | ±180° | ||||||
| Joint 3 | ±166° | ±163° | |||||
| Joint 6 | ±270° | ||||||
| Joint Speeds | Joint 1, 2 | 120°/s | |||||
| Joint 3 | 180°/s | ||||||
| Joint 4, 5 | 180°/s | 150°/s | |||||
| Joint 6 | 180°/s | ||||||
| Repeatability (mm) | ±0.1 | ||||||
| IP | IP54 (robot arm), IP32 (control box), IP40 (robot stick) | ||||||
| Cleanroom Class | ISO Class 5 | ||||||
| Operating Temperature (°C) | 0 to 50 | ||||||
| Power Supply | 100-240 VAC, 50-60 Hz | 22-60 VDC | 100-240 VAC, 50-60 Hz | 22-60 VDC | |||
| Cable length | 3 m/12 m | 1.5 m | 3 m/12 m | 1.5 m | |||
| I/O Ports | Control Box | Digital In: 16 Digital Out: 16 Analog In: 2 Analog Out: 1 |
|||||
| Tool | Digital In: 4 Digital Out: 4 Analog In: 1 Analog Out: 0 |
||||||
| I/O Interface | 3 × COM, 1 × HDMI, 3 × LAN, 4 × USB2.0, 2 × USB3.0 | ||||||
| Communication | RS232, Ethernet (master), Modbus TCP/RTU (master & slave) | ||||||
| Integrated Camera | 5M pixels, color (AOI tasks: 5M/1.2M; others:1.2M) | ||||||
| I/O Power Supply | 24 V 1.5 A (control box and tool) | ||||||
| Programming Environment | TMflow, flowchart based | ||||||
| SEMI S2 Certified | No | Yes | No | Yes | |||
Dimensions
TM5-700
TM5-900
TM12
TM14
Flange
Control Box
TM 5 – 700
- Range di lavoro (mm): 700
- Portata massima (kg): 6
- Velocità massima (m/s): 1,1
TM 5 – 900
- Range di lavoro (mm): 900
- Portata massima (kg): 4
- Velocità massima (m/s): 1,4
TM 12
- Range di lavoro (mm): 1300
- Portata massima (kg): 12
- Velocità massima (m/s): 1,3
TM 14
- Range di lavoro (mm): 1100
- Portata massima (kg): 14
- Velocità massima (m/s): 1,1
-
TM Collaborative Robots Tutorial 1 - Unboxing and Initial Set Up
Meet the Omron TM Collaborative Robot Series to assist your automation needs. In this video we will show you how to unbox the Cobot and do the initial set up. There are several Cobot in the TM Series depending on your needs. Here we will be using the TM5 – 700 models to explain the common features.
06:34
Tutorial sui robot collaborativi Omron 1 - Apertura dell'imballaggio e configurazione iniziale
Scopri i robot collaborativi OMRON TM per soddisfare le tue esigenze di automazione. In questo video mostreremo come estrarre dall'imballaggio il cobot OMRON TM e come eseguire la configurazione iniziale. La serie di cobot Omron TM include diversi modelli a seconda delle esigenze. In questa sede utilizzeremo i modelli TM5 - 700 per illustrare le caratteristiche comuni.
-
TM Collaborative Robots Tutorial 2 – Programming the Basic Motions
Meet the Omron TM Collaborative Robot Series to assist your automation needs. In this video, we would like to show you the basics of how to make the Cobot move.
06:40
Tutorial sui robot collaborativi Omron 2 - Programmazione dei movimenti di base
Scopri i robot collaborativi OMRON TM per soddisfare le tue esigenze di automazione. In questo video, desideriamo illustrare le nozioni di base su come azionare i cobot OMRON TM.
-
TM Collaborative Robots Tutorial 3 – How to Program Using Flow Chart Software
Meet the Omron TM Collaborative Robot Series to assist your automation needs. In this video, you can learn how to use the software, called “TMflow,” to program the Cobots. TMflow has an intuitive user interface that allows you to easily create a program using flowcharts.
05:23
Tutorial sui robot collaborativi Omron 3 - Come eseguire la programmazione utilizzando il software dei flussi logici
Scopri i robot collaborativi OMRON TM per soddisfare le tue esigenze di automazione. In questo video, imparerai a utilizzare il software, denominato "TMflow", per programmare il cobot OMRON TM. TMflow è dotato di un'interfaccia utente intuitiva che consente di creare facilmente un programma utilizzando i diagrammi di flusso.
-
TM Collaborative Robots Tutorial 4 – How to Attach a Gripper to the Cobot
Meet the Omron TM Collaborative Robot Series to assist your automation needs. In this video, we will show you how to use grippers with your Cobot.
04:37
Tutorial sui robot collaborativi Omron 4 - Come collegare una pinza al cobot
Scopri i robot collaborativi OMRON TM per soddisfare le tue esigenze di automazione. In questo video, mostreremo come utilizzare le pinze con il cobot OMRON TM.
-
TM Collaborative Robots Tutorial 5 – Vision Calibration and Vision Node
Meet the Omron TM Collaborative Robot Series to assist your automation needs. In this video, we will show you how to start using the built-in camera and the integrated vision system for your applications. One of the biggest advantages of this Cobot is that you can rapidly create an application in which you want the Cobot to see and recognize the object that it is working on. You do not need additional lens nor lights.
05:13
Tutorial sui robot collaborativi Omron 5 - Calibrazione e nodo della visione
Scopri i robot collaborativi OMRON TM per soddisfare le tue esigenze di automazione. In questo video, ti mostreremo come iniziare a utilizzare la telecamera e il sistema di visione integrati per le tue applicazioni. Uno dei principali vantaggi di questo cobot OMRON TM è la possibilità di creare rapidamente un'applicazione in cui il cobot OMRON TM veda e riconosca l'oggetto sul quale sta lavorando. Non sono necessarie luci o lenti aggiuntive.
-
TM Collaborative Robots Tutorial 6 – Pick and Place Using Vision
Meet the Omron TM Collaborative Robot Series to assist your automation needs. In this video, we finished the vision calibration and explored some of the vision tasks. So now we are ready to start creating an application that utilizes the camera and the vision system. We will pick up a cylinder from this hole and place it here.
06:46
Tutorial sui robot collaborativi Omron 6 - Operazioni "pick and place" con il sistema di visione
Scopri i robot collaborativi OMRON TM per soddisfare le tue esigenze di automazione. In questo video, abbiamo completato la calibrazione della visione ed esaminato alcune delle attività di visione. Ora siamo pronti a creare un'applicazione che utilizzi la telecamera e il sistema di visione. Raccoglieremo un cilindro da questo foro e lo posizioneremo qui.
-
TM Collaborative Robots Tutorial 7 – Updating TMFlow software
Meet the Omron TM Collaborative Robot Series to assist your automation needs. In this video we will show how to update the TMFlow software. We constantly have software updates, so make sure you update Collaborative Robots software so that you can utilize the newest features.
04:49
Tutorial sui robot collaborativi Omron 7 - Aggiornamento del software TMflow
Scopri i robot collaborativi OMRON TM per soddisfare le tue esigenze di automazione. In questo video mostreremo come aggiornare il software TMflow. Gli aggiornamenti software sono molto frequenti, quindi assicurati di aggiornare il software dei robot collaborativi OMRON TM per usufruire delle funzionalità più recenti.
-
TM Collaborative Robots Tutorial 8 – Communication via ModBus
Meet the Omron TM Collaborative Robot Series to assist your automation needs. The TM Collaborative Robots is capable of different types of communications. On this video we will focus on using ModBus TCP communication in TMFlow software.
07:15
Tutorial sui robot collaborativi Omron 8 - Comunicazione tramite ModBus
Scopri i robot collaborativi OMRON TM per soddisfare le tue esigenze di automazione. I robot collaborativi OMRON TM sono in grado di supportare diversi tipi di comunicazione. In questo video, ci concentreremo sull'utilizzo della comunicazione TCP ModBus nel software TMflow.
-
TM Collaborative Robots Tutorial 9 – Advanced Motion Methods
Meet the Omron TM Collaborative Robot Series to assist your automation needs. In this video we will discuss the different types of advanced motions that Omron’s Collaborative Robots can achieve. We will focus on some of the different types of motions that our Cobots can use to fit in your applications.
04:32
Tutorial sui robot collaborativi Omron 9 - Metodi di movimento avanzato
Scopri i robot collaborativi OMRON TM per soddisfare le tue esigenze di automazione. In questo video parleremo dei diversi tipi di movimenti avanzati che i robot collaborativi OMRON TM possono effettuare. Ci concentreremo su alcuni dei diversi tipi di movimenti che i nostri cobot possono eseguire per adattarsi alle tue applicazioni.
Brochure
Mostra tutto brochure
Certificati
Mostra tutto certificati
Cataloghi
Mostra tutto cataloghi
Scheda tecnica sulla sicurezza della batteria
Mostra tutto scheda tecnica sulla sicurezza della batteria
Iscrivetevi agli aggiornamenti di prodotti
Newsletter sulle ultime novità e innovazioni in termini di prodotti, soluzioni e servizi direttamente nella vostra casella di posta.
Grazie per la tua iscrizione! Riceverai a breve una E-mail di conferma con un link per attivare il servizio. Questo sistema di iscrizione è stato scelto per ottemperare alla legge sulla privacy e garantisce la riservatezza del tuo indirizzo E-mail.
Purtroppo abbiamo problemi tecnici. Il tuo modulo non è stato ricevuto correttamente. Ci scusiamo per l'inconveniete e ti chiediamo per favore di riprovare più tardi.
DownloadDocumentazione di prodotto
Scarica le schede tecniche, i manuali e le brochure.
Vai al Download CenterCorsi di formazione
Accedete ai corsi di formazione offerti dai nostri tecnici qualificati. Dal livello principiante ad avanzato.
Visualizzate i corsi di formazione
